Name: 180 Degrees U bend silicone elbow
Brand: Standards
Rating: 5.0 (66 reviews)

You are here: Home » Products » Silicone Hose » Automotive Silicone Hose » 180 Degrees U bend silicone elbow

Model:
180 Degrees Silicone Elbow Hose
Brand:
Standards
Code:
3917390000

Product Description

180 Degrees U bend silicone elbow

180 Degree Elbow Silicone Hose Bend

STANDARDS's line of silicone hose products are used in coolant and high temperature applications. The hose products are available for turbo and charge air coolers in straights and in formed hoses for engines.

180° Elbow Silicone Hoses

1.180 Degrees U bend silicone elbow Applications

•Heavy duty truck and bus engines

•Buses and passenger cars

•Vehicles with diesel engine

•Marine

•Agriculture & Forestry

•For use in high vibration, hot and cold air aspiration units

Silicone Hose 180 Degree Elbow

2.180 Degrees U bend silicone elbow Spec.:

Inner and Cover:silicone rubber

Reinforce ply:3-4ply Polyester/Aramid/Glass fiber

Color: Blue, Red, Black etc. (Inner lining can adopt different colors)

Wall Thickness: 4mm, 4.5mm, 5mm, or as request

Length: as request

Size Tolerance: ID

Surface: Smooth or Cloth

LOGO: STANDARDS, or as request

Operating Temperatures

Polyester braid reinforced: -54℃ to +220℃ (-65℉ to 428℉)

Aramid braid reinforced: -54℃ to +260℃ (-65℉ to 500℉)

NOTE:

It is used for air/water, not fuel/oil

For fuel and oil use, hose need to be lined with FLUORO SILICONE

3.180 Degrees U bend silicone elbow Specification

Bore mm	Bore "	Leg Length	Center line distance
16	5/8"	76mm	48 mm
19	3/4"	76mm	58 mm
22	7/8"	76mm	66 mm
25	1"	102mm	76 mm
28	1 1/8"	102mm	86 mm
32	1 1/4"	102mm	96 mm
35	1 3/8"	102mm	106 mm
38	1 1/2"	102mm	114 mm
45	1 3/4"	102mm	136 mm
51	2"	127mm	152 mm
57	2 1/4"	127mm	170 mm
60	2 3/8"	127mm	180 mm
63	2 1/2"	127mm	190 mm
70	2 3/4"	127mm	210 mm
76	3"	140mm	228 mm
